Suitable for ventilating the building
During summer, the large opening can be used to ventilate the building. The glazing is made of 10 mm safety glass and protected by slender fine-frame profiles.
Approved for application in emergency exits and escape routes
The profile system is tested for a minimum service life of 1 million cycles and approved for application in emergency exits and escape routes according to UNE EN 16.005
Protected glazing
The glazing is made of 10 mm safety glass and protected by slender fine-frame profiles.
Fields of application
- Exterior doors or interior doors
- Public buildings
- Shopping arcades
- Showrooms (car dealers or similar)
Maximum door dimensions
(Door panel weight and basic technical conditions can be critical)
- Maximum system width: 5540 mm
- Maximum clear passage width: 2000 mm
- Maximum clear passage height: 2500 mm
Supplementary equipment/options
- Floor-integrated guide tracks
- Combined electromechanical locking device
